Product Name : SCK/BYB Finish Boring Head
Product Introduction
  • SYIC-17380 only contains the body, not including SYIC-17400 BYB Micrometer Adjustable Boring Head.



MODEL NO.TYPESYIC - 17400
ASSEMBLE TOOL HOLDER
d1d2Ll1l2DWEIGHT (KGS)
MIN.MAX.
SYIC- 17382 SCK1 x BYB19 SCK1 19 22.5 11 51 35 4.75 18 0.36
SYIC - 17384 SCK1 x BYB22 SCK1 22 29.5 11 51 35 4.75 20 0.36
SYIC - 17386 SCK2 x BYB29 SCK2 29 41 14 61 45 6.5 25 0.37
SYIC - 17388 SCK3 x BYB38 SCK3 38 50 18 90 70 7.7 35 0.41
SYIC - 17390 SCK4 x BYB48 SCK4 48 65 22 84 60 7.7 41 0.59
SYIC - 17392 SCK5 x BYB62 SCK5 62 90 28 110 80 12.7 54 0.7
SYIC - 17394 SCK6 x BYB82 SCK6 82 110 36 150 110 15.7 67 1.05
