series:

ER COLLET

proimages/Products/Accessories/Collet/ER_figure.jpg

MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	SIZE RANGE
MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	METRIC	INCHES
5250-122-008	ER8	8	8.5	13.5	10.8	2.98	1.5	1 ~ 5mm	1/16" ~ 3/16"
5250-122-011	ER11	11	11.5	18	13.5	3.8	2.5	1 ~ 7mm	1/16" ~ 1/4"
5250-122-016	ER16	16	17	27.5	20.8	6.26	4	1 ~ 10mm	1/16" ~ 13/32"
5250-122-020	ER20	20	21	31.5	23.9	6.36	4.8	1 ~ 13mm	1/16" ~ 1/2"
5250-122-025	ER25	25	26	34	25.9	6.66	5	1 ~ 16mm	3/32" ~ 5/8"
5250-122-032	ER32	32	33	40	30.9	7.16	5.5	2 ~ 20mm	1/16" ~ 3/4"
5250-122-040	ER40	40	41	46	34.9	7.66	7	3 ~ 26mm	1/8" ~ 1"
5250-122-050	ER50	50	51.85	60	46	12.6	8.5	6 ~ 34mm	7/32" ~ 1-5/16"

ER-E COLLET

proimages/Products/Accessories/Collet/ER-E-figure.jpg

MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	SIZE RANGE
MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	METRIC	INCHES
5250-113-011	ER11E	11	11.5	18	13.5	3.8	2.5	2 ~ 7mm	1/16" ~ 9/32"
5250-113-016	ER16E	16	17	27.5	20.8	6.26	4	2 ~ 10mm	1/16" ~ 13/32"
5250-113-020	ER20E	20	21	31.5	23.9	6.36	4.8	2 ~ 13mm	1/16" ~ 1/2"
5250-113-025	ER25E	25	26	34	25.9	6.66	5	2 ~ 16mm	3/32" ~ 5/8"
5250-113-032	ER32E	32	33	40	30.9	7.16	5.5	3 ~ 20mm	1/8" ~ 3/4"
5250-113-040	ER40E	40	41	46	34.9	7.66	7	3 ~ 26mm	1/8" ~ 1"

ER-ES STEEL SEALED COLLET

proimages/Products/Accessories/Collet/ER-ES_figure.jpg

MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	SIZE RANGE
MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	METRIC	INCHES
5250-114-011	ER11ES	11	11.2	18	13.5	3.8	2.5	3 ~ 7mm	3/32" ~ 1/4"
5250-114-016	ER16ES	16	16.6	27.5	20.8	6.25	4	3 ~ 10mm	3/32" ~ 13/32"
5250-114-020	ER20ES	20	20.6	31.5	23.9	6.36	4.8	3 ~ 13mm	1/8" ~ 1/2"
5250-114-025	ER25ES	25	25.6	34	25.9	6.66	5	3 ~ 16mm	7/32" ~ 5/8"
5250-114-032	ER32ES	32	32.6	40	30.9	7.16	5.5	3 ~ 20mm	7/32" ~ 3/4"
5250-114-040	ER40ES	40	40.6	46	34.9	7.66	7	3 ~ 26mm	7/32" ~ 1"

ERS METALLIC SEALED COLLET

proimages/Products/Accessories/Collet/ERS-figure.jpg

MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	SIZE RANGE
MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	METRIC	INCHES
5250-111-011	ERS11	11	11.2	18	13.5	3.8	2.5	3 ~ 7mm	3/32" ~ 1/4"
5250-111-016	ERS16	16	16.75	27.5	20.8	6.26	4	3 ~ 10mm	3/32" ~ 13/32"
5250-111-020	ERS20	20	20.7	31.5	23.9	6.36	4.8	3 ~ 13mm	1/8" ~ 1/2"
5250-111-025	ERS25	25	25.7	34	25.9	6.66	5	3 ~ 16mm	7/32" ~ 5/8"
5250-111-032	ERS32	32	32.7	40	30.9	7.16	5.5	3 ~ 20mm	7/32" ~ 3/4"
5250-111-040	ERS40	40	40.7	46	34.9	7.66	7	3 ~ 26mm	7/32" ~ 1"

ER-EO SEALED COLLET

proimages/Products/Accessories/Collet/EREO-figure.jpg

MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	SIZE RANGE
MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	METRIC	INCHES
5250-115-011	ER11EO	11	11.2	18	13.5	3.8	2.5	3 ~ 7mm	1/8" ~ 9/32"
5250-115-016	ER16EO	16	16.6	27.5	20.8	6.26	4	3 ~ 10mm	1/8" ~ 13/32"
5250-115-020	ER20EO	20	20.6	31.5	23.9	6.36	4.8	3 ~ 13mm	1/8" ~ 1/2"
5250-115-025	ER25EO	25	25.6	34	25.9	6.66	5	3 ~ 16mm	1/8" ~ 5/8"
5250-115-032	ER32EO	32	32.6	40	30.9	7.16	5.5	3 ~ 20mm	1/8" ~ 3/4"
5250-115-040	ER40EO	40	40.6	46	34.9	7.66	7	3 ~ 26mm	1/8" ~ 1"

ERS COOLANT COLLET FID TYPE

proimages/Products/Accessories/Collet/ERS-FID_figure.jpg

MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	SIZE RANGE
MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	METRIC	INCHES
5250-188-011	ERS11-FID	11	11.2	18	13.5	3.8	2.5	3 ~ 5mm	3/32" ~ 1/4"
5250-188-016	ERS16-FID	16	16.75	27.5	20.8	6.26	4	3 ~ 7mm	3/32" ~ 13/32"
5250-188-020	ERS20-FID	20	20.7	31.5	23.9	6.36	4.8	3 ~ 9mm	1/8" ~ 3/8"
5250-188-025	ERS25-FID	25	25.7	34	25.9	6.66	5	3 ~ 14mm	7/32" ~ 5/8"
5250-188-032	ERS32-FID	32	32.7	40	30.9	7.16	5.5	3 ~ 20mm	7/32" ~ 3/4"
5250-188-040	ERS40-FID	40	40.7	46	34.9	7.66	7	3 ~ 26mm	7/32" ~ 1"

ERS COOLANT COLLET FOD TYPE

proimages/Products/Accessories/Collet/ERS-FOD-figure.jpg

MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	SIZE RANGE
MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	METRIC	INCHES
5250-112-011	ERS11-FOD	11	11.2	18	13.5	3.8	2.5	3 ~ 5mm	3/32" ~ 1/4"
5250-112-016	ERS16-FOD	16	16.75	27.5	20.8	6.26	4	3 ~ 7mm	3/32" ~ 5/16"
5250-112-020	ERS20-FOD	20	20.7	31.5	23.9	6.36	4.8	3 ~ 9mm	1/8" ~ 3/8"
5250-112-025	ERS25-FOD	25	25.7	34	25.9	6.66	5	3 ~ 14mm	7/32" ~ 9/16"
5250-112-032	ERS32-FOD	32	32.7	40	30.9	7.16	5.5	3 ~ 20mm	7/32" ~ 3/4"
5250-112-040	ERS40-FOD	40	40.7	46	34.9	7.66	7	3 ~ 26mm	7/32" ~ 1"

ER COOLANT COLLET FID TYPE

proimages/Products/Accessories/Collet/ER-FID-figure.jpg

MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	SIZE RANGE
MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	METRIC	INCHES
5250-126-016	ER16-FID	16	16.6	27.5	20.8	6.26	4	3 ~ 9mm	1/8" ~ 5/16"
5250-126-020	ER20-FID	20	20.6	31.5	23.9	6.36	4.8	3 ~ 12mm	1/8" ~ 3/8"
5250-126-025	ER25-FID	25	25.6	34	25.9	6.66	5	3 ~ 16mm	1/8" ~ 9/16"
5250-126-032	ER32-FID	32	32.6	40	30.9	7.16	5.5	3 ~ 20mm	1/8" ~ 3/4"
5250-126-040	ER40-FID	40	40.6	46	34.9	7.66	7	4 ~ 26mm	5/32" ~ 1"

ER COOLANT COLLET FOD TYPE

proimages/Products/Accessories/Collet/ER-FOD-figure.jpg

MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	SIZE RANGE
MODEL NO.	TYPE	d1	d2	L	l1	l2	l3	METRIC	INCHES
5250-127-016	ER16-FOD	16	16.6	27.5	20.8	6.26	4	3 ~ 7mm	1/8" ~ 5/16"
5250-127-020	ER20-FOD	20	20.6	31.5	23.9	6.36	4.8	3 ~ 9mm	1/8" ~ 3/8"
5250-127-025	ER25-FOD	25	25.6	34	25.9	6.66	5	3 ~ 14mm	1/8" ~ 9/16"
5250-127-032	ER32-FOD	32	32.6	40	30.9	7.16	5.5	3 ~ 20mm	1/8" ~ 3/4"
5250-127-040	ER40-FOD	40	40.6	46	34.9	7.66	7	4 ~ 26mm	5/32" ~ 1"
5250-127-050	ER50-FOD	50	51.45	60	46	12.6	8.5	6 ~ 34mm	1/4" ~ 1-5/16"

ER-TC RIGID TAP COLLET

proimages/Products/Accessories/Collet/ER-TC_figure.jpg

MODEL NO.	TYPE	d3	L	l1	CAPACITY
5250-116-016	ER16	16	27.5	17.5	M3 ~ M12
5250-116-020	ER20	20	31.5	20.7	M3 ~ M17
5250-116-025	ER25	25	34	23	M3 ~ M22
5250-116-032	ER32	32	40	27.34	M3 ~ M27
5250-116-040	ER40	40	46	31.34	M3 ~ M27
5250-116-050	ER50	50	60	38.9	M10 ~ M33

ER-TC RIGID TAP SEALED COLLET

proimages/Products/Accessories/Collet/ER-TC_sealed_figure.jpg

MODEL NO.	TYPE	d3	L	l1	l2	CAPACITY
5250-117-016	ER - TCO16	16	27.5	17.5	18 ~ 22	M5 ~ M10
5250-117-020	ER - TCO20	20	31.5	20.7	18 ~ 25	M5 ~ M17
5250-117-025	ER - TCO25	25	34	23	18 ~ 25	M5 ~ M22
5250-117-032	ER - TCO32	32	40	27.34	18 ~ 28	M5 ~ M27
5250-117-040	ER - TCO40	40	46	31.34	18 ~ 28	M5 ~ M27

ER-TC RIGID TAP COOLANT COLLET FOD TYPE

proimages/Products/Accessories/Collet/ER-TC-FOD_figure.jpg

MODEL NO.	TYPE	d3	L	l1	l2	CAPACITY
5250-118-016	ER-TC16	16	27.5	17.5	18 ~ 22	M5 ~ M10
5250-118-020	ER-TC20	20	31.5	20.7	18 ~ 25	M5 ~ M12
5250-118-025	ER-TC25	25	34	23	18 ~ 25	M5 ~ M20
5250-118-032	ER-TC32	32	40	27.34	18 ~ 28	M5 ~ M27
5250-118-040	ER-TC40	40	46	31.34	18 ~ 28	M5 ~ M27

ER FLOATING TAP COLLET

proimages/Products/Accessories/Collet/ER-floating_figure.jpg

MODEL NO.	TYPE	d2	L	l1	l2	l3	SIZE RANGE
MODEL NO.	TYPE	d2	L	l1	l2	l3	METRIC	INCHES
5250-148-016	FT16	16	26.6	22	3	18	1.4 ~ 6mm	0.141" ~ 0.220"
5250-148-020	FT20	20	31	22.6	4	17.9	2.24 ~ 7mm	0.141" ~ 0.255"
5250-148-025	FT25	25	33.5	24.5	6	19.1	2.5 ~ 10mm	0.141" ~ 0.367"
5250-148-032	FT32	32	43.3	30	7	24.5	4.5 ~ 12.5mm	0.168" ~ 0.480"
5250-148-040	FT40	40	54	40	8	33	6 ~ 14mm	0.255" ~ 0.697"

SKX COLLET

proimages/Products/Accessories/Collet/SKX_figure.jpg

MODEL NO.	TYPE	d1	d2	L	l1	SIZE RANGE
MODEL NO.	TYPE	d1	d2	L	l1	METRIC	INCHES
5250-790-006	SKX-6	10.2	8.8	25	21.4	1 ~ 6mm	1/8" ~ 1/4"
5250-790-010	SKX-10	15.5	13.2	30.5	26.3	2 ~ 10mm	1/8" ~ 3/8"
5250-790-013	SKX-13	20	17	39.05	34	2 ~ 13mm	-
5250-790-016	SKX-16	24.5	20.05	45.1	40	2 ~ 16mm	1/8" ~ 5/8"
5250-790-020	SKX-20	29	24.85	54.2	48.95	3 ~ 20mm	1/8" ~ 3/4"
5250-790-025	SKX-25	35.5	30	57.1	51.5	3 ~ 25mm	1/8" ~ 1"

SKS COLLET UP TYPE

proimages/Products/Accessories/Collet/SKS-UP_figure.jpg

MODEL NO.	TYPE	L	l1	d1	SIZE RANGE
5250-658-006	SKS-6-UP	25.7	21.4	9.26	1 ~ 6mm
5250-658-010	SKS-10-UP	32	26.8	13.6	2 ~ 10mm
5250-658-013	SKS-13-UP	39.1	33.6	17	2 ~ 13mm
5250-658-016	SKS-16-UP	46	40	21	2 ~ 16mm
5250-658-020	SKS-20-UP	54.3	49	24.9	3 ~ 20mm
5250-658-025	SKS-25-UP	58.2	51.5	31	3 ~ 25.4mm

SKS COLLET E TYPE

proimages/Products/Accessories/Collet/SKS-E_figure.jpg

MODEL NO.	TYPE	L	l1	d2	SIZE RANGE
5250-834-006	SKS-6E	25.7	21.4	8.76	1 ~ 6mm
5250-834-010	SKS-10E	32	26.8	13	2 ~ 10mm
5250-834-013	SKS-13E	39.1	33.6	17	2 ~ 13mm
5250-834-016	SKS-16E	46	40	20.5	2 ~ 16mm
5250-834-020	SKS-20E	54.3	49	24.9	3 ~ 20mm

SKS SEALED COLLET

proimages/Products/Accessories/Collet/SKS_sealed_figure.jpg

MODEL NO.	TYPE	L	l1	d1	SIZE RANGE
5250-792-010	SKS-10C	32	26.8	12.8	3 ~ 10mm
5250-792-013	SKS-13C	39.1	33.6	16.5	3 ~ 13mm
5250-792-016	SKS-16C	46	40	20.2	3 ~ 16mm
5250-792-020	SKS-20C	54.3	49	24.4	3 ~ 20mm
5250-792-025	SKS-25C	58.2	51.5	30	6 ~ 25.4mm

SLC COLLET

proimages/Products/Accessories/Collet/SLC_figure.jpg

MODEL NO.	TYPE	D	d	L	l1	T	SIZE RANGE
MODEL NO.	TYPE	D	d	L	l1	T	METRIC	INCHES
5250-S37-006	SLC-6	10	8	36	24	M6	3 ~ 6mm	1/8" ~ 1/4"
5250-S37-008	SLC-8	15	12	51.5	22.2	M8	3 ~ 8mm	1/8" ~ 5/16"
5250-S37-012	SLC-12	18	14.5	57	25.45	M10	3 ~ 12mm	1/8" ~ 1/2"
5250-S37-020	SLC-20	27	21	70	35	M12	3 ~ 20mm	1/8" ~ 3/4"
5250-S37-025	SLC-25	32.4	25	80	43.5	M16	6 ~ 25mm	1/4" ~ 1"

SLC SEALED COLLET

proimages/Products/Accessories/Collet/SLC_sealed_figure.jpg

MODEL NO.	TYPE	D	d	L	l1	T	SIZE RANGE
MODEL NO.	TYPE	D	d	L	l1	T	METRIC	INCHES
5250-S38-006	SLC6-CO	10	8	36	24	M6	3 ~ 6mm	1/8" ~ 1/4"
5250-S38-008	SLC8-CO	15	12	51.5	22.2	M8	3 ~ 8mm	1/8" ~ 5/16"
5250-S38-012	SLC12-CO	18	14.5	57	25.45	M10	3 ~ 12mm	1/8" ~ 1/2"
5250-S38-020	SLC20-CO	27	21	70	35	M12	3 ~ 20mm	1/8" ~ 3/4"
5250-S38-025	SLC25-CO	32.4	25	80	43.5	M16	6 ~ 25mm	1/4" ~ 1"

EBL COLLET

proimages/Products/Accessories/Collet/EBL_figure.jpg

MODEL NO.	TYPE	L	l1	d	d1	T	SIZE RANGE
MODEL NO.	TYPE	L	l1	d	d1	T	METRIC	INCHES
5250-277-006	EBL-6	53	15	8.5	10.5	M6	3 ~ 6mm	1/8" ~ 1/4"
5250-277-008	EBL-8	58	22.2	12	15.09	M8	3 ~ 8mm	1/8" ~ 5/16"

EBL SEALED COLLET

proimages/Products/Accessories/Collet/EBL_sealed_figure.jpg

MODEL NO.	TYPE	L	l1	d	d1	T	SIZE RANGE
MODEL NO.	TYPE	L	l1	d	d1	T	METRIC	INCHES
5250-278-006	EBL-6-CO	53	15	8.5	10.5	M6	3 ~ 6mm	1/8" ~ 1/4"
5250-278-008	EBL-8-CO	58	22.2	12	15.09	M8	3 ~ 8mm	1/8" ~ 5/16"

HYC REDUCTION SLEEVE For Hydraulic Chuck

proimages/Products/Accessories/Collet/HYC_figure.jpg

MODEL NO.	TYPE	D	d2	L	l1	SIZE RANGE
5253-266-012	HYC12	12	16.5	47	45	3 ~ 8mm
5253-266-020	HYC20	20	24	52.5	50.5	3 ~ 16mm
5253-266-025	HYC25	25	29	56.5	54.5	6 ~ 20mm
5253-266-032	HYC32	32	35.5	62.5	60.5	6 ~ 25mm

HSC STRAIGHT COLLET For MLD Milling Chuck

proimages/Products/Accessories/Collet/HSC_figure.jpg

MODEL NO.	TYPE	D	d2	L	l2	SIZE RANGE
5253-269-012	HSC12	12	18.5	47	2	3 ~ 8mm
5253-269-020	HSC20	20	26	54	2	4 ~ 16mm
5253-269-025	HSC25	25	29	60	2	4 ~ 20mm
5253-269-032	HSC32	32	37.5	72	2	6 ~ 25mm
5253-269-A32	HSC1/2"	12.7	18.5	47	2	1/8" ~ 5/16"
5253-269-A48	HSC3/4"	19.5	26	54	2	1/4" ~ 5/8"
5253-269-A64	HSC1"	25.4	29	60	2	1/8" ~ 3/4"
5253-269-A72	HSC1-1/4"	31.75	37.5	72	2	3/8" ~ 1"

STRAIGHT COLLET For MLD Milling Chuck

proimages/Products/Accessories/Collet/SSC_figure.jpg

MODEL NO.	TYPE	D	d2	L	l1	SIZE RANGE
5253-618-012	SSC12	12	19	44.5	42.5	3 ~ 8mm
5253-618-016	SSC16	16	19	50	46	3 ~ 12mm
5253-618-020	SSC20	20	25	52.5	49	3 ~ 16mm
5253-618-025	SSC25	25	31	60	55	3 ~ 20mm
5253-618-032	SSC32	32	37.5	64.6	59.6	3 ~ 25mm
5253-618-042	SSC42	42	48	75	69	3 ~ 32mm
5253-618-A48	SSC3/4"	3/4"	25	52.5	49	1/8" ~ 5/8"
5253-618-A64	SSC1"	1"	31	60	55	1/8" ~ 3/4"
5253-618-A72	SSC1-1/4"	1-1/4"	37.5	64.6	59.6	1/8" ~ 1"

STRAIGHT SEALED COLLET For Hydraulic Chuck

proimages/Products/Accessories/Collet/SSC_sealed_figure.jpg

MODEL NO.	TYPE	D	d2	L	l1	SIZE RANGE
5253-S36-012	SSC12-C	12	16	40	38	3 ~ 8mm
5253-S36-020	SSC20-C	20	25	52.9	49.4	3 ~ 16mm
5253-S36-025	SSC25-C	25	30.5	52.5	50.5	3 ~ 20mm
5253-S36-032	SSC32-C	32	37.5	66	61	3 ~ 25mm
5253-S36-042	SSC42-C	42	48	75	69	3 ~ 32mm
5253-S36-A32	SSC1/2"-C	1/2"	16	46.5	44.5	1/8" ~ 3/8"
5253-S36-A48	SSC3/4"-C	3/4"	25	52.9	49.4	1/8" ~ 5/8"
5253-S36-A64	SSC1"-C	1"	30.5	52.5	50.5	1/8" ~ 3/4"
5253-S36-A72	SSC1-1/4"-C	1-1/4"	37.5	66	61	1/8" ~ 1"

EOC COLLET FORM B

proimages/Products/Accessories/Collet/EOC_figure.jpg

MODEL NO.	TYPE	E-NO	L	l1	D	d1	Fig.	SIZE RANGE
MODEL NO.	TYPE	E-NO	L	l1	D	d1	Fig.	METRIC	INCHES
5250-689-025	SYOZ-25	462E	52	13	35	32.9	1	3 ~ 25mm	1/8" ~ 1"
5250-119-032	EOC32-B	467E	60	17	43.7	41.3	2	4 ~ 32mm	1/8" ~ 1-1/4"

TG COLLET

proimages/Products/Accessories/Collet/TG_figure.jpg

MODEL NO.	TYPE	L	l1	D	d1	SIZE RANGE
MODEL NO.	TYPE	L	l1	D	d1	METRIC	INCHES
5250-691-075	TG 75	46.84	13.6	26.97	26.84	3 ~ 16mm	3/32" ~ 3/4"
5250-691-100	TG 100	60.32	16.32	35.02	32.5	3 ~ 25mm	3/32" ~ 1"
5250-691-150	TG 150	76.2	18	50.83	47.7	4 ~ 38mm	5/32" ~ 1-1/2"

TG SEALED COLLET

proimages/Products/Accessories/Collet/TG_sealed_figure.jpg

MODEL NO.	TYPE	L	l1	D	d1	SIZE RANGE
MODEL NO.	TYPE	L	l1	D	d1	METRIC	INCHES
5250-696-100	TG 100	60.32	16.32	35.02	32.5	3 ~ 25mm	3/32" ~ 1"
5250-696-150	TG 150	76.2	18	50.83	47.7	4 ~ 38mm	5/32" ~ 1-1/2"

series:

Coolant Application of ER-TCO Rigid Tap Sealed Collet

Coolant Application of ER-TCO Rigid Tap Sealed Collet-SBT

Installation and Application of SKS Sealed Clamping Nut and SKS Sealed Collet

Back

Collet Series

Product Description
